Nova+ 120

Magnet Wire Elongation Tester

Features:

  • Meets NEMA, or IEC and JIS specifications
  • N.I.S.T traceability
  • Elongation up to 50%
  • Adjustable % elongation up to 50%
  • Wireless output (WR-100 receiver required)
  • Color touchscreen interface
  • Wire holding post and clamps accommodates wide range of wire sizes:
    44 AWG - 8 AWG
    (0.05 mm - 3 mm)
  • 120VAC/3.0amps @ 50/60Hz
    240VAC/1.5amps @ 50/60Hz

The Nova+ 120 Magnet Wire Elongation Tester performs the elongation test according to NEMA, or IEC and JIS specifications. The tester can be calibrated traceable to NIST The elongation tester elongates a specimen of annealed
magnet wire with a test length of 10 inches (NEMA) or 250 mm (IEC) to a predetermined % elongation up to 50% or to failure. The maximum elongation is 50 %.
The tester can test wire sizes 44 AWG to 8 AWG (0.05 mm to 3.15 mm).
Ball screw and linear guide assembly together with reliable electronics in a totally enclosed chassis provide a sturdy and
reliable test platform.

Dimensions:

6 1/2" L x 6" W x 24" H
17cm L x 15cm W x 61cm H
